- Complies ANS/EIA, RS-310-D, DIN41491, IEC297-2, DIN41494, DART7, GB/T3047.2-92, and ETSI standard ;
- Compatible with 19-inch international standard and ETSI standard;
- Elegance look, profound technical, precise dimension with modern taste, add value to your projects;
- Removable side doors, convenient to operate;
- International popular color tempered glass door ;
- Install caster and supporting feet, move easily, and firm ;
- Removable side panel and rear door, easy to assemble or dismantle, lock is optional ;
- The bottom cable entry can be covered , the size is adjustable according to the requirement ;
- Varies optional accessories, reliable quality ;
- Max static loading capacity:700KG
- Point of differences: Front door : the tempered glass door have the color bars on both side for decoration. The color of color bars is optional. Both sides of the door with mesh to keep ventilated; Rear door: planar mesh/solid rear door for option;
- Material: SPCC cold rolling steel, plate Mounting angle: 2.0mm, frame Front door: 1.2mm, others 1.0mm
- Dimension: 800 x 800 x 2000mm
- Capacity: 42U
|
eTEM series Network Server Racks order code |
|
Width(mm) |
Content |
Depth（mm） |
|
600 |
800 |
900 |
1000 |
|
600 |
47u |
eTEM6647 |
eTEM6847 |
eTEM6947 |
eTEM6047 |
|
42u |
eTEM6642 |
eTEM6842 |
eTEM6942 |
eTEM6042 |
|
37u |
eTEM6637 |
eTEM6837 |
eTEM6937 |
eTEM6037 |
|
32u |
eTEM6632 |
eTEM6832 |
eTEM6932 |
eTEM6032 |
|
27u |
eTEM6627 |
eTEM6827 |
eTEM6927 |
eTEM6027 |
|
22u |
eTEM6622 |
eTEM6822 |
eTEM6922 |
eTEM6022 |
|
18u |
eTEM6618 |
|
|
|
|
800 |
47u |
eTEM8647 |
eTEM8847 |
eTEM8947 |
eTEM8047 |
|
42u |
eTEM8642 |
eTEM8842 |
eTEM8942 |
eTEM8042 |
|
37u |
eTEM8637 |
eTEM8837 |
eTEM8937 |
eTEM8037 | |
|
