| Product Description:
Features：
1：High quality SGCC with 1.0mm thickness
2: High-strength painting case, Wear non-foaming
3: Supports 12"*9.6" mainboard and PS/2 power supply.
4: Set front & back HDD area ,can supply up to six drive bays
|
eT2PC68A |
|
Material |
High-grade SGCC, thickness with 1.0mm |
|
D*W*H(mm) |
685*485*90 |
|
Packing(mm) |
755*550*145 |
|
G.W.（KG) |
10.5 |
|
Specification |
Quantity(unit) |
|
Mainboard |
12"×13" |
1 |
|
CPU types |
Intel/AMD |
1 |
|
Drive frame |
3.5"HDD (hot-swap) |
6 |
|
CD-ROM |
1 |
|
3.5”FDD |
1 |
|
Front panel |
USB2.0 port |
1 |
|
Light switch plate |
1 |
|
Alarm indicator (HDD) |
1 |
|
Power supply |
ATX (2U) power supply |
1 |
|
I/O rear window |
Onboard Device |
0 |
|
Backplane support |
SATAII/SAS |
|
|
Cooling fan |
8025*4（standard） |
5 |
|
Sliding rail |
Supporting |
1 |
|
Expansion slot |
|
5 |
|
Application: |
|
1 |
Large company for high-intensity computing； |
|
2 |
The application of the internet,(such as web,mail, file servers, data-base, integration,game server,etc.) |
|
3 |
Virtual hosting, ASP ,conection,etc,of application； |
|
4 |
Network storage |
|
